APPLICATIONS

• Architectural Indoor & Outdoor Entrance Facade
• Luminous Ceilings & Walls
• Indoor Ad Signage
• Outdoor Ad Signage
• Backlighting
• Architectural Lighting
• Curved Applications
• Compact, Space-Sensitive Applications
• Retail Applications
• …And Many More!

SAFETY

• Electric Code Compliance Please make sure to install LUXFLEX™ in accordance with standard national and local electrical codes.

• Electrical Connectors LUXFLEX™ allows for up to six (6) connections per sheet.

CUSTOMIZATIONS

• Custom IP Ratings Available for Outdoor & Damp Locations Please reach out to our team for more information.

• Custom Wattage Available Please reach out to our team for specific power requests.

  INSTALLATION

  • Field Cuttable Following the black cut lines on the sheet, the smallest piece that can be cut is 2″ x 3″ or 50.8mm x 76.2mm.
  • Environment Indoor location safe. Outdoor location safe with IP65 rating upon request.
  • Operating Temperature -13˚F ~ +140˚F (-20˚C ~ +60˚C)
  • Ambient Temperature -13˚F ~ +158˚F (-25˚C ~ +70˚C)
  • Mounting Mount with 3M adhesives or standard screws. All LUXFLEX™sheets feature 3M adhesive on the reverse side of the sheet and 9 holes for mounting with screws.
  • Heat Sink Not required for installation.
  • Tiling Multiple Sheets To tile LUXFLEX, identify the female Molex^® connector and match the polarity of the connecting wire according to the polarity indicated next to the sheet connector. White wire is negative for Neutral White, Yellow wire is negative for Warm White, and Black wire is positive. The male Molex connector must always be facing up when inserting the wire into the connector.
  • Curved Applications LUXFLEX™ may be pressure flexed for curved or radius applications to best fit your environment.
