Fabric Light Box (Profile 120)
Fabric Light Box (Profile 120)
The Profile 120 Fabric Light Box is our most popular and multifunctional marketing solution providing the best value to our clients. Designed for all types of traditional applications, including mounting, hanging, or freestanding displays, it’s no wonder this profile is as popular as it is. Considering that our Fabric Light Boxes are all designed to last a lifetime, it’s a no-brainer why clients love Profile 120. A one-time purchase will help your business maximize it’s ROI for years to come.
This profile of our line of Fabric Light Boxes has two options of backlighting: Lattice Technology and Perimeter Lighting. Integrating the technology of these lighting techniques with a frameless anodized aluminum frame allows for seamless application to virtually any environment. The 120mm thickness of the Profile 120 Fabric Light Box is ideal for illuminating and displaying graphics of all sizes. Because of its versatile mounting capabilities (hanging, wall mounted, and free-standing), Profile 120 is the most in demand out of our entire line of Fabric Light Boxes.
LUXMESH
The technology of Lattice Lighting provides high quality LED lighting with the latest SMD technology. Lattice technology has low energy consumption and low heat generation, with a wide viewing angle of 120°. LED lattice lights are ideal to backlight large areas, creating a bright display with no hot spots.
PERIMETER LIGHTING
Perimeter Lighting uses LED modules that only use 15 Watts per LED module with a life expectancy of over 50,000 hours – an energy efficient lighting solution. Replacement of the modules is a simple and convenient task and can be easily done on the spot.. All lighting components are UL approved.
Product Specification
Safety Standard
UL Listed Electric Sign (E340398)
Frame
- Depth: 4.7″ (120mm)
- Frame Size
- Minimum Graphic Size: 18″ x 18″ (457mm x 457mm)
- Maximum Graphic Size: 120″ (3048mm) x any length
- Outside Dimensions Equivalent to graphic size
- Orientation
- Portrait
- Landscape
Finish
- Standard: Silver anodized aluminum
- Custom Color: Powder coated (available upon request)
Packaging
- Pre-Assembled Individually packed, depending on size
- Shipped Knocked Down (Disassembled) For large scale projects
Mounting Options
- Wall Mount: With wall mount anchors
- Hanging: With aviation cable or eyehooks
- Freestanding: Attaches to foot stand
- Standard feet
- Heavy-duty stainless steel feet
- Custom Mounting: Hardware kits available for your desired application
Lighting Options
- Color-Changing RGB Provides unique colored effect
- Easy Dimming Provides control of the lighting intensity
Fabric
- Graphic Size/Visual Area Equivalent to frame size
- Material Type: 100% Flame-retardant polyester
- Print Process: Digital dye-sublimation
- Installation: Silicone beading (stitched edge)
- Flexible PVC: 0.55″ x 0.098″ (14mm x 2.5mm)
- Diffuser Available upon request
- Fabrics Backer: Included for optimal light reflection
- White
- Solid colors available
Lighting
- Light Source: LUXMESH™ LED Lattice Lighting
- Wide Beam Angle: 120°
- NICHIA LED
- 9-inch lattice: LTS 9 @ 3.7W/pc
- 19-inch lattice: LTS 19 @ 7.5W/pc
- 38-inch lattice: LTS 38 @ 15W/pc
- Light Source: Perimeter Power Lighting
- CREE LED
- Power Consumption: 15W per module
- Life Expectancy: 50,000+ hours
- Easy Replacement: Can be installed on-site
- Standard Color Termperature (CCT): 6500K
- Available Color Temperatures (CCT)
- 4100K
- 5300K
- 6500K
- Operating Voltage: 24Vdc
Power Supply
- Remote Class 2 Power Supply: Handles up to 60W
- Input Voltage: 100-240Vac, 50-60Hz
- Universal Power Supply: Available upon request
- Daisy Chain: Link multiple light boxes for easy, clean installation & minimal visible wiring using just one outlet
Powered by Lattice and Perimeter Lighting technology, the Profile 120 Fabric Light Box is ideal for displaying graphics of all sizes, providing bright and even illumination. The slim profile and frameless design provides a clean, sleek, and modern look, and also allows for seamless application and the ability to blend in easily with any environment.
The Profile 120 Fabric Light Box is used in different environments spanning from retail to exhibition, displaying promotions and branding efforts, as well as illuminating art work and graphics. To view some of our projects with the Profile 120 Light Box application, click here.
Product Features
Quick Graphics Changes
Power: 12V/24V
Slim Profile
80% Energy Efficient
Frameless Design
Plug & Play
Wall Mount – Seamless Application
Custom Sizes
Outstanding Brightness
Custom Frame Colors
Even Lighting – No Dark Spots
Pre-Assembled – Ships Ready To Use
Hanging
Free Standing
Certifications
