LUXFIT™ CLASSIC LED LIGHT PANEL

Home PRODUCTS LUXFIT™ CLASSIC LED LIGHT PANEL

LUXFIT™ Classic LED Light Panel

The LUXFIT™ LED Light Panel is the new innovative light source that is designed to be ultimately slim, have even illumination, and be customizable to your design. This new innovative technology and design has been shown in all types of markets such as Retail, Signage, Display & Fixture, and Architecture & Design. Well-known customers such as Sony, Versace, CVS, HP and Hitachi have already adapted this new technology.

Download Spec


Product Features

  • IP65_300x300px image
    Damp Location Available
  • null
    Slim & Thin Design
  • null
    Custom Sizes
  • null
    Custom Color Temps
  • null
    Illuminated Ceilings & Walls
  • null
    Illuminated Shelves & Fixtures
  • null
    Strong Color Rendering 80+
  • null
    Frameless Design
  • null
    Outstanding Brightness
  • null
    Even Lighting
  • null
    Custom & Irregular Shapes (Modular)
  • null
    Multi-Panel Illumination by Tiling

Assured Quality

null

E477011

100% QC

100% Quality Control

3 YEAR WARRANTY image

Limited Warranty

CE
null

E341676

DOWNLOAD
SPECIFICATION
PHOTOMETRICS
FAQs
INSTALLATION
APPLICATIONS
DOWNLOAD

PDF_iconLUXFIT™ Classic Specification Sheet

PDF_iconStatic White Drivers & Controls Specification Sheet

PDF_iconLUXFIT™ Installation Guide

PDF_iconLuxury Illuminated Faux Alabaster Bar Case Study with LUXFIT

PDF_iconLuxury Cosmetics Flagship Store Design Case Study with LUXFIT, LUXLINEAR & LUXLINE

PDF_iconCustom Backlit Luxury Hotel Suite Case Study with LUXFLEX & LUXFIT

PDF_iconOversize Glass Illumination
Case Study with LUXFIT

download-file-icons-vector-ies

LUXFIT™ 3000K IES File

download-file-icons-vector-ies

LUXFIT™ 6500K IES File

PDF_iconLedconn Catalog

SPECIFICATION

MECHANICAL

Physical Characteristics

  • Max. Panel Size 60” (1524mm) x 120” (3048mm)
  • Min. Panel Size Any size less than the max.
  • Acrylic Thickness 5/32” (4mm) 15/64” (6mm)
  • Overall Thickness
    • Widths < 2.5 ft (750mm) 1/4” (6.5mm)
    • Widths ≥ 2.5 ft (750mm) 3/8” (9.5mm)
  • Weight 1.5 lbs per sq. ft. (7.32kg per sq. m.)
  • Operating Temperature -22° F (-30°C) to 122°F (50°C)

Compliance & Regulatory Approval

  • UL E477011 · cUL E477011 · RoHs · CE · Lead Free · Warranty 3 years

Construction & Base Material

  • Light Guide Panel Material PMMA Optical Grade Acrylic panel
  • Reflective Film Material PET
  • Flexible Diffuser Material PET
  • Rigid Diffuser Material Extruded acrylic paper-masked sheet
  • Heat Sink Material Aluminum

ELECTRICAL

Parameters

  • Lamp Life 50,000+ hours
  • Color Rendering Index (CRI/Ra) 80+ across all color temperatures · 90+ available upon request
  • Standard Colors 3000K · 4100K · 5300K · 6500K
  • Custom Color Temperatures Available Please inquire for more information.

Dimming

  • Pulse-width modulation dimming (PWM)
  • 0-10V dimming
  • DMX/DALI
  • Magnetic low voltage (MLV)
  • Remote control plugin
  • Inline plugin

Power Supply

  • Input Voltage 12VDC  & 24VDC
  • Power Consumption Varies depending on panel size and selected strip configuration.
  • Please Use Only with Class 2 Power Supply.
  • Connector Type
    • DC barrel jack
    • Hardwire
    • Molex® connectors
  • Wiring in Parallel Multiple LUXFIT™ light panels may share a single power supply when connected in parallel.

LUXFIT™ LED Light Panel - Standard Sizes

Item#Panel SizeBrightnessPower Consumption
X162016" x 20" x 5/16"7 W
X182418" x 24" x 5/16"13 W
X222822" x 28" x 5/16"3000 Lux21 W
X242424" x 24" x 5/16"17 W
X243624" x 36" x 5/16"25 W
X304030" x 40" x 5/16"40 W
PHOTOMETRICS

LUXFIT™ CLASSIC STANDARD
12V / 6500K / 24″ X 36″

Angle In
Degrees
Average
0-Deg
Average
45-Deg
Average
90-Deg
45122713021353
55123913381423
65124313681470
75112712701420
859109961081
FAQs

Frequently Asked Questions About LUXFIT LED Light Panels

What is the difference between dot pattern and V cutting?

Dot pattern and V cutting are two common methods used to produce light panels. LEDCONN uses dot pattern technology to produce our LUXFIT light panels. This allows the production of a superior product in important ways, such as:

  • Shortened panel production time
  • Simplified adjustment of light density
  • More even light distribution across the full panel

Conversely, V cutting uses evenly etched lines of the same width with varying depths. This process takes longer and offers less efficient management of light density and distribution.

Can you tell me more about dot pattern technology?

To distribute the light uniformly and create the absolute evenness of light, white reflective dots are silkscreened (or laser etched) onto each panel so that the illumination will transmit from edge to edge without a dark center. Depending on the size and shape of the panels, the design of how the dots are distributed will vary. The white reflective dots are smaller and widely spread on areas closer to the LEDs, and conversely, larger white reflective dots are narrowly spaced on areas farther away from LEDs.

Every material used to create the LUXFIT™ LED Light Panel has been distinctively chosen to ensure optimal quality. Each panel is made of the optical grade PMMA acrylic to ensure the transmittance of light will always be at its best performance.

What are the practical applications of LUXFIT light panels?

LUXFIT light panels are specifically designed for use in retail spaces. They can be used to highlight:

  • POP displays
  • ATM areas
  • Window displays
  • Branded displays
  • Movie posters
  • Menu boards
  • Exhibits

These fixtures also complement architectural elements like:

  • Ceilings
  • Walls
  • Counters
  • Floors

Adding light panels to retail environments increases light without adding unattractive or unnecessary lighting fixtures. Visit our online gallery to see the possibilities.

What is the largest panel size available from LEDCONN?

LEDCONN currently stocks light panels with a maximum size of 5 feet by 10 feet (1524 millimeters by 3048 millimeters).

How are LUXFIT panels installed?

LEDCONN provides a comprehensive installation guide with each panel. Review these instructions carefully to successfully install panels. If problems occur during the installation process, our representatives are available to answer questions. Email sales@ledconn.com or call (714) 256-2111 for assistance.

How long is the lead time for LUXFIT panels?

Lead time depends on quantity:

  • 10 units or less, roughly 1–2 weeks
  • Between 10 and 25 units, 3–4 weeks
  • More than 25 units, 6–8 weeks

High volume orders may qualify for expedited service with a lead time of 3–4 weeks.

Does LEDCONN offer a warranty for LUXFIT panels?

LEDCONN panels come with a limited warranty, but misuse or alteration of the product may void the agreement.

Are custom panel sizes available?

LEDCONN specializes in custom lighting solutions. Contact our sales representatives to discuss the specifications of your project.

Can LEDCONN produce organic shapes with LED light panels?

Customers that include an AutoCAD or DXF file with their project can order organic LED light panels such as non-perfect circles. For pieces that exceed the maximum sizes, multiple pieces may be suggested.

INSTALLATION

PANEL PROFILE

LUXFIT™ PANEL ANATOMY

APPLICATIONS

APPLICATIONS

  • Luminous Ceilings & Walls
  • Luminous Shelving
  • Backlighting
  • Architectural Lighting (Interior & Exterior)
  • Hospitality Lighting
  • Cove Lighting
  • Accent Lighting
  • Task Lighting
  • Illuminated Custom Retail Fixtures & Displays
  • Illuminated Signage & Branding
  • Compact, Space-Sensitive Applications

TRANSLUCENT SURFACE MATERIALS

Consider illuminating any of the following translucent surface materials with LUXFIT™ Classic!
